Abov MC96F6332D User Manual

MC96F6432
June 22, 2018 Ver. 2.9 103
10.12.5 Register Map
Table 10-3 Interrupt Register Map
Name
Address
Dir
Default
Description
IE
A8H
R/W
00H
Interrupt Enable Register
IE1
A9H
R/W
00H
Interrupt Enable Register 1
IE2
AAH
R/W
00H
Interrupt Enable Register 2
IE3
ABH
R/W
00H
Interrupt Enable Register 3
IP
B8H
R/W
00H
Interrupt Priority Register
IP1
F8H
R/W
00H
Interrupt Priority Register 1
EIFLAG0
C0H
R/W
00H
External Interrupt Flag 0 Register
EIPOL0L
A4H
R/W
00H
External Interrupt Polarity 0 Low Register
EIPOL0H
A5H
R/W
00H
External Interrupt Polarity 0 High Register
EIFLAG1
A6H
R/W
00H
External Interrupt Flag 1 Register
EIPOL1
A7H
R/W
00H
External Interrupt Polarity 1 Register
10.12.6 Interrupt Register Description
The interrupt register is used for controlling interrupt functions. Also it has external interrupt control registers.
The interrupt register consists of interrupt enable register (IE), interrupt enable register 1 (IE1), interrupt enable
register 2 (IE2) and interrupt enable register 3 (IE3). For external interrupt, it consists of external interrupt flag 0
register (EIFLAG0), external interrupt polarity 0 high/low register (EIPOL0H/L), external interrupt flag 1 register
(EIFLAG1) and external interrupt polarity 1 register (EIPOL1).
