Abov MC96F6332D User Manual

MC96F6432
June 22, 2018 Ver. 2.9 111
11.1.3 Register Map
Table 11-1 Clock Generator Register Map
Name
Address
Dir
Default
Description
SCCR
8AH
R/W
00H
System and Clock Control Register
OSCCR
C8H
R/W
20H
Oscillator Control Register
11.1.4 Clock Generator Register Description
The clock generator register uses clock control for system operation. The clock generation consists of System
and clock control register and oscillator control register.
11.1.5 Register Description for Clock Generator
SCCR (System and Clock Control Register) : 8AH
7
6
5
4
3
2
1
0
–
–
–
–
–
–
SCLK1
SCLK0
–
–
–
–
–
–
R/W
R/W
Initial value : 00H
SCLK [1:0]
System Clock Selection Bit
SCLK1
SCLK0
Description
0
0
INT RC OSC (f
IRC
) for system clock
0
1
External Main OSC (f
XIN
) for system clock
1
0
External Sub OSC (f
SUB
) for system clock
1
1
Not used
