11.13.22 Register Map
Table 11-24 USI1 Register Map
Name
Address
Dir
Default
Description
USI1BD
F3H
R/W
FFH
USI1 Baud Rate Generation Register
USI1DR
F5H
R/W
00H
USI1 Data Register
USI1SDHR
F4H
R/W
01H
USI1 SDA Hold Time Register
USI1SCHR
F7H
R/W
3FH
USI1 SCL High Period Register
USI1SCLR
F6H
R/W
3FH
USI1 SCL Low Period Register
USI1SAR
EDH
R/W
00H
USI1 Slave Address Register
USI1CR1
E9H
R/W
00H
USI1 Control Register 1
USI1CR2
EAH
R/W
00H
USI1 Control Register 2
USI1CR3
EBH
R/W
00H
USI1 Control Register 3
USI1CR4
ECH
R/W
00H
USI1 Control Register 4
USI1ST1
F1H
R/W
80H
USI1 Status Register 1
USI1ST2
F2H
R
00H
USI1 Status Register 2
11.13.23 USI1 Register Description
USI1 module consists of USI1 baud rate generation register (USI1BD), USI1 data register (USI1DR), USI1 SDA
hold time register (USI1SDHR), USI1 SCL high period register (USI1SCHR), USI1 SCL low period Register
(USI1SCLR), USI1 slave address register (USI1SAR), USI1 control register 1/2/3/4 (USI1CR1/2/3/4), USI1
status register 1/2 (USI1ST1/2).
11.13.24 Register Description for USI1
USI1BD (USI1 Baud- Rate Generation Register: For UART and SPI mode) : F3H
7
6
5
4
3
2
1
0
USI1BD7
USI1BD 6
USI1BD 5
USI1BD 4
USI1BD 3
USI1BD 2
USI1BD 1
USI1BD 0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : FFH
USI1BD[7:0]
The value in this register is used to generate internal baud rate in
asynchronous mode or to generate SCK1 clock in SPI mode. To
prevent malfunction, do not write ‘0’ in asynchronous mode and do
not write ‘0’ or ‘1’ in SPI mode.
NOTE) In common with USI1SAR register, USI1BD register is
used for slave address register when the USI1 I2C mode.
