The LCD driver is controlled by the LCD Control Register (LCDCRH/L). T
he LCLK[1:0] determines the
frequency of COM signal scanning of each segment outpu
t
.
A
RESET clears the LCD control register LCDCRH
and LCDCRL values to logic
‘
0
’
.
The LCD display can continue operating during IDLE and ST
OP modes if a sub
-frequency clock is used as LCD
clock source.
