9.5 P2 Port
9.5.1 P2 Port Description
P2 is 8-bit I/O port. P2 control registers consist of P2 data register (P2), P2 direction register (P2IO), P2 pull-up
resistor selection register (P2PU) and P2 open-drain selection register (P2OD). Refer to the port function
selection registers for the P2 function selection.
9.5.2 Register description for P2
P2 (P2 Data Register) : 90H
7
6
5
4
3
2
1
0
P27
P26
P25
P24
P23
P22
P21
P20
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
P2[7:0]
I/O Data
Note) Do not use the “direct bit test and branch” instruction for input port, more detail information is at
Appendix B.
Example) Avoid direct input port bit test and branch condition as below
If(P20) → if(P2 & 0x01)
P2IO (P2 Direction Register) : B9H
7
6
5
4
3
2
1
0
P27IO
P26IO
P25IO
P24IO
P23IO
P22IO
P21IO
P20IO
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
P2IO[7:0]
P2 Data I/O Direction
0
Input
1
Output
NOTE: SS1 function possible when input
