ADCMT 7351A User Manual

7351 Series Digital Multimeter Operation Manual
6.7.2 Output Data Format
6-19
Main header Description
DCV Measurement function DC voltage measurement (DCV)
ACV AC voltage measurement (ACV)
R2W Resistance measurement (2W)
DCI DC current measurement (DCI)
ACI AC current measurement (ACI)
ADV AC voltage (AC+DC coupling) measurement (ACV(AC+DC))
ADI AC current (AC+DC coupling) measurement (ACI(AC+DC))
DOD Diode measurement (Diode)
R2L Low power resistance measurement (2W
RCT Continuity test (Cont)
FRQ Frequency measurement (Freq)
Sub header Description Priority
O Error information Range over 1
O Calculation Scaling error 1
E Err D (dB/dBm calculation error) 2
H Calculation result information Comparator result HIGH 3
PGO3
LLOW3
MMAX data 4
IMIN data 4
AAVE data 4
BdB data 5
WdBm data 5
S Scaling calculation data 6
N NULL calculation data 7
_ None of the above 8
