7351 Series Digital Multimeter Operation Manual
5.2 Measurement Functions
5-8
5.2 Measurement Functions
For more information on the measurement function description, refer to Chapter 4.
This chapter describes the parameters set in MENU that is used in the measurement function.
5.2.1 Continuity Measurement
Setting the continuity threshold constant
The continuity threshold constant can be selected in the range between 1 and
1000 from ‘BEEP’ in category in .
Press to determine the setting.
5.3 Measurement Range and Auto-Range
5.3.1 Measurement Function and Range Structure
Table 5-2 shows the range structure corresponding to the measurement function.
Table 5-2 Measurement Function and Range Structure
DCV
ACV
ACV
(AC+DC)
2W LP-2W DCI
ACI
ACI
(AC+DC)
FREQ Continuity Diode
200 mV 200 mV 200 mV
2000 mV 2000 mV 200 200 2000 mV 2000 mV
20 V 20 V 2000 2000 200 mA 200 mA 20 V 2000
200 V 200 V 20 k 20 k 2000 mA 2000 mA 200 V
1000 V 700 V 200 k 200 k 10 A 10 A 700 V
2000 k 2000 k
20 M 20 M
200 M
NOTE: The range settings for each function are saved.
For the frequency function, the range is not switched in the frequency range but
switched in the voltage range.
