7351 Series Digital Multimeter Operation Manual
7.2 Interface Specifications
7-13
7.2 Interface Specifications
Item Specifications
Remote control
Remote command Compliance with the command format for ADC, SCPI and R64 series.
Interface
7351E USB
7351E + Option 03 RS-232, USB, Comparator output, External trigger signal, Complete sig-
nal output
7351A GPIB, USB, External trigger signal, Complete signal output
USB
Standard Compliance with USB1.1
Connector Type B
GPIB (7351A)
Standard Compliance with IEEE488.2
Connector 24-pin Anphenol
Interface functions SH1, AH1, T5, L4, SR1, RL1, PP0, DC1, DT1, C0, E2
Output format ASCII
Addressing 31 kinds of talker/listener addresses can be specified from the front
panel.
RS-232 (7351E + Option 03)
Standard Compliance with EIA-232
Connector D-Sub9 pin
Baud rate 9600, 4800, 2400, 1200, 600, 300
Parity Even number (EVEN), odd number (ODD), or none
Number of data bits 7 bits or 8 bits
Number of stop bits 1 bit or 2 bits
Echo ON, OFF
