7351 Series Digital Multimeter Operation Manual
4.2.1 Measurement Functions
4-16
NOTE: When the sampling rate is set to SLOW, the sampling rate indicator alternates between the dark
“S” and bright “S”.
WARNING: Do not apply voltage that exceeds the maximum allowable applied voltage. Fire or electric
shocks due to the failure of this instrument may occur.
Figure 4-12 Frequency Measurement (FREQ)
Table 4-9 Maximum Allowable Applied Voltage (FREQ)
Between V and COM terminals
1000 Vpeak, 700 Vrms, 2.2 10
7
VHz
Between COM terminal and chassis (grounding) 500 V
To Next Page
