7351 Series Digital Multimeter Operation Manual
5.9.7 Statistical Calculation
5-31
5.9.7 Statistical Calculation
1. Function
1. This function calculates the maximum value, minimum value, average value,
standard deviation, and range of the measurement data that is stored in the mea-
surement memory.
2. The following calculations are performed at the same time in the statistical cal-
culation.
• Number of samples S
CNT
= (Number of data) - (Number of overload), in the
specified range
• Maximum value S
MAX
= Maximum value of the data to be calculated
• Minimum value S
MIN
= Minimum value of the data to be calculated
• Average value
• Dispersion S
PTP
= | S
MAX
- S
MIN
|
• Standard deviation
3. All measurement data except for overload (OL) and calculation error data can be
used for the calculation
2. Performing the calculation
1. Select STAT in
2. Press to perform the calculation.
‘LAST’ is displayed if no data is stored in the measurement data memory.
To Next Page
