7351 Series Digital Multimeter Operation Manual
7. SPECIFICATIONS
7-1
7. SPECIFICATIONS
7.1 Specifications
Unless otherwise specified, the measurement accuracy of this instrument is guaranteed for one year under
the following conditions: Temperature; 23 5C, relative humidity; 85% or less (75% or less in a resistance
measurement of larger than 20 M and low power resistance measurement of larger than 2M)
7.1.1 DC Voltage Measurement (DCV)
Maximum allowable applied voltage
Noise rejection ratio
Input
terminal
Range
Maximum display Resolution
Input impedance
Measurement accuracy *1
(% of reading + digits)
Temperature
coefficient
(ppm of reading +
digits)/C
FAST
MED/
SLOW1, 2
FAST
MED/
SLOW1, 2
FAST MED SLOW1, 2 AZ ON AZ OFF
V-COM 200 mV 199.99 199.999 10 V1 V More than 1 G 0.012+2 0.012+7 0.012+6 15+0.85 15+2
2000 mV 1999.9 1999.99 100 V10 V More than 1 G 0.011+2 0.011+5 0.011+2 15+0.2 15+1.5
20 V 19.999 19.9999 1 mV 100 V 10 M1% 0.015+2 0.015+5 0.015+5 20+0.25 20+1.5
200 V 199.99 199.999 10 mV 1 mV 10 M1% 0.015+2 0.015+5 0.015+5 20+0.25 20+1.5
1000 V 1099.9 1099.99 100 mV 10 mV 10 M1% 0.015+2 0.015+5 0.015+5 20+0.25 20+1.5
*1 For AZ ON. For AZ OFF, two digits are added to the digit section.
Between V and COM terminals 1000 Vpeak
Between COM and the chassis 500 V
FAST MED/SLOW1, 2
Effective common mode noise rejection ratio
(Unbalanced impedance of 1 k)
50/60 Hz 0.08%
Approx. 60 dB Approx. 120 dB
Normal mode noise rejection ratio
50/60 Hz 0.08%
0 dB Approx. 60 dB
