ADCMT 7351A - DC Current Measurement (DCI)

7351 Series Digital Multimeter Operation Manual
7.1.4 DC Current Measurement (DCI)
7-5
7.1.4 DC Current Measurement (DCI)
Input
terminal
Range
Maximum display Resolution
Resistance
between input
terminals
Measurement accuracy *1
(% of reading + digits)
Temperature
coefficient
(ppm of reading +
digits)/C
FAST
MED/
SLOW1, 2
FAST
MED/
SLOW1, 2
FAST MED SLOW1, 2 AZ ON AZ OFF
mA-
COM
200 mA 199.99 199.999 10 A1 A0.5 or less 0.03+2 0.03+10 0.03+10 40+1 40+2
2000 mA 1999.9 1999.99 100 A 10 A0.5 or less 0.05+2 0.05+7 0.05+6 50+0.7 50+1.5
10 A-
COM
10 A 10.999 10.9999 1 mA 100 A0.06 or less 0.15+2 0.15+7 0.15+6 50+0.7 50+1.5
*1 For AZ ON. For AZ OFF, two digits are added to the digit section.
Maximum allowable
applied current
Input protection Fuse replacement
Between mA and
COM terminals
2000 mA 2 A/250 V fast-blow fuse which is compliant
with IEC60127 sheet1
On the rear panel
Between 10 A and
COM terminals
10 A 15 A/250 V fast-blow fuse with 10000 A break-
ing capacity
Contact us to repair
