7351 Series Digital Multimeter Operation Manual
3.4.3 Connecting the Power Cable
3-11
3.4.3 Connecting the Power Cable
This instrument includes a three-core power cable with a grounding conductor. To prevent accidents
caused by electric shocks, only use the included power cable and securely connect to the ground through
a three-pin power outlet.
1. Check that the included power cable is not damaged.
WARNING: Never use a damaged power cable. Doing so may cause an electrical
shock.
2. Connect the AC power connector on the rear panel of this instrument to a three-
pin power outlet that has a ground terminal by using the included power cable
(See Figure 3-5).
Figure 3-5 Connecting the Power Cable
WARNING:
1. Use a suitable power cable for the power supply voltage.
2. To prevent any danger of electrical shock, connect the power cable to a three-pin power outlet that is con-
nected to a ground terminal. The instrument will not be grounded if an extension cord, which does not include
a ground terminal, is used.
3.4.4 Selecting the Power Supply Frequency
Select a power supply frequency according to the area where this instrument is used.
Select the following from 'LINE' in the category in .
50 The commercial power supply frequency is 50 Hz.
60 The commercial power supply frequency is 60 Hz.
For more information on navigating menus, refer to 5., “MENU OPERATION AND FUNCTION
DESCRIPTION”.
