7351 Series Digital Multimeter Operation Manual
4.2.2 Setting the Measurement Range
4-17
4.2.2 Setting the Measurement Range
Increases the measurement range by one level and fixes the range.
Decreases the measurement range by one level and fixes the range.
Switches the measurement range between auto-range and fixed range.
4.2.3 Changing the Measurement Speed and Display Digit
Press .
The measurement speed and display digit are changed as shown in Table 4-10 and Table 4-14.
In the frequency measurement, the sampling rate is used to set the gate time. For more information on the
frequency measurement, refer to Section 4.2.1, “Measurement Functions.”
Table 4-10 Measurement Speed (a) when in the HOLD OFF (Trigger source: IMMED)
Sampling rate
Measurement speed (Measurement time)
Integration
time
DCV
DCI
2W
LP-2W
ACV
ACI
Continuity
Diode
ACV(AC+DC)
ACI(AC+DC)
FAST 140 times/s (7.1 ms) 30 times/s (33 ms) 2 ms
MED (50 Hz) 40 times/s (25 ms) 19 times/s (52 ms) 1 PLC
MED (60 Hz) 40 times/s (25 ms) 19 times/s (52 ms) 1 PLC
SLOW1 9.5 times/s (105 ms) 4.7 times/s (212 ms) 100 ms
SLOW2 4.9 times/s (205 ms) 2.4 times/s (412 ms) 200 ms
Conditions: Auto-range: OFF, Auto-zero: OFF, Calculation: OFF, and Display: OFF
UP
DOWN
AUTO
RATE
