7351 Series Digital Multimeter Operation Manual
4.1.1 Front Panel Description
4-4
4.1.1.8 SHIFT/EXIT/LOCAL Key
1. SHIFT Sets or cancels the SHIFT mode.
• In the setting mode
2. EXIT Exits from MENU and returns to the measurement state display.
(The data in process of changing the setting is not saved.)
• In the remote operation
3. LOCAL Changes to the LOCAL operation when the instrument is in the
remote state.
NOTE: The LOCAL operation cannot be set if the LLO(LOCAL
LOCKOUT) command is set from the GPIB interface.
4.1.1.9 Front Input Section for Measurement
1. INPUT V Hz terminal HI terminal used for the DC voltage, AC voltage, resistance,
diode, and frequency measurements
2. COM terminal LO terminal used for the DC voltage, AC voltage, DC current, AC
current, resistance, diode, and frequency measurements
3. mA terminal HI terminal used for the 200-mA and 2000-mA ranges of the DC
and AC current measurements
4. 10 A terminal HI terminal used for the 10-A range of the DC and AC current
measurements
4.1.1.10 CAT II (Marking)
This display shows that the safety of this instrument satisfies the measurement category II which is com-
pliant with IEC 61010-1 Ed.2. Measurement category II is for measurements performed on circuits direc-
tory connected to the low voltage installation.
