7351 Series Digital Multimeter Operation Manual
8.3.3 Calibration Point
8-6
8.3.3 Calibration Point
1. Perform calibration for each range of each measurement function. For more information on relation-
ships between functions and ranges, refer to Table 5-2.
2. First, calibrate the zero point in each range calibration.
3. In the DC voltage measurement and DC current measurement, calibrate the zero point and full-scale
point.
4. In the resistance measurement, calibrate the zero point and full-scale point.
5. In the low-power resistance measurement, calibrate the zero point and full-scale point.
6. In the AC voltage measurement and AC current measurement, calibrate the zero point, calibration
point1, calibration point2, and calibration point3.
7. In the ACV(AC+DC) and ACI(AC+DC) measurements, no calibration is required because the instru-
ment is calibrated when the calibration is performed in the DC voltage and AC voltage measurements.
8. In the continuity and diode measurements, no calibration is required because the instrument is cali-
brated when the calibration is performed in the DC voltage and AC voltage measurements.
9. In the frequency measurement, no calibration is required.
Recommended input range: +5% to -10% for each calibration point
Table 8-1 Calibration Point (1 of 2)
Measurement
function
Range Zero Calibration point1 Calibration point2 Calibration point3
DCV 200 mV Short 190 mV - -
2000 mV Short 1900 mV - -
20 V Short 19 V - -
200 V Short 190 V - -
1000 V Short 1000 V - -
ACV
ACV(AC+DC)
200 mV Short 5 mV, 1 kHz 19 mV, 1 kHz 190 mV, 1 kHz
2000 mV Short 50 mV, 1 kHz 190 mV, 1 kHz 1900 mV, 1 kHz
20 V Short 500 mV, 1 kHz 1900 mV, 1 kHz 19 V, 1 kHz
200 V Short 5000 mV, 1 kHz 19 V, 1 kHz 190 V, 1 kHz
700 V Short 7 V, 1 kHz 70 V, 1 kHz 700 V, 1 kHz
2W 200 Short 190 --
2000 Short 1900 --
20 k Short 19 k --
200 k Short 190 k --
2000 k Short 19000 k --
20 M Short 19 M --
200 M Short 100 M --
To Next Page
