7351 Series Digital Multimeter Operation Manual
6.4 USB
6-11
6.4 USB
6.4.1 Overview
A USB (Universal Serial Bus), which is compliant with the USB1.1 standard, is included in this instrument
as standard.
By connecting multiple instruments to the USB ports on a personal computer, the functions of the instru-
ments can be set, measurement data can be read from the personal computer, and the automatic measure-
ment system can be set up easily.
NOTE: This instrument may not operate with all personal computers, hubs, etc.
6.4.2 USB Specifications
• Standard: Compliance with USB1.1
• Connector: USB B type (female)
• ID: Any number from 1 to 127 can be set as USBid.
• Remote/Local: Function is available.
• Input command: ASCII strings command which sets functions and the query command
• Output format ASCII strings which describe measurement data and query reply output
• Driver: The USB driver for ADC instruments is used.
6.4.3 Setting Up the USB Port
6.4.3.1 Connecting to a Personal Computer
Connect the connection cable to the USB connector (B type) on the rear panel of this instrument and the
USB connector on the personal computer.
Insert the connector completely when connecting.
Use the USB hub when connecting several instruments to a personal computer.
6.4.3.2 USBid Setting
The USBid setting menu can be used when USB is selected for the interface.
1. Enter any address from 1 to 127 in ‘USBid’ in in .
2. Press to apply the setting.
To Next Page
