7.1.9 Measurement Time and Display Digits
7-10
7.1.9 Measurement Time and Display Digits
For HOLD OFF (Trigger source: IMMED)
For HOLD ON (Trigger source: EXT)
RATE setting
Measurement speed (In Auto-range OFF)
Integration time
DCV
DCI
2W
LP-2W
ACV
ACI
Continuity
Diode
ACV(AC+DC)
ACI(AC+DC)
FAST 140 times/s (7.1 ms) 30 times/s (33 ms) 2 ms
MED (50 Hz) 40 times/s (25 ms) 19 times/s (52 ms) 1 PLC
MED (60 Hz) 40 times/s (25 ms) 19 times/s (52 ms) 1 PLC
SLOW1 9.5 times/s (105 ms) 4.7 times/s (212 ms) 100 ms
SLOW2 4.9 times/s (205 ms) 2.4 times/s (412 ms) 200 ms
Conditions: Auto-range: OFF, Auto-zero: OFF, Calculation: OFF, and Display: OFF
RATE setting
Measurement speed (In Auto-range OFF)
Integration time
DCV
DCI
2W
LP-2W
ACV
ACI
Continuity
Diode
ACV(AC+DC)
ACI(AC+DC)
FAST 80 times/s (12.5 ms) 45 times/s (22 ms) 2 ms
MED (50 Hz) 32 times/s (31 ms) 17 times/s (58 ms) 1 PLC
MED (60 Hz) 37 times/s (27 ms) 19 times/s (52 ms) 1 PLC
SLOW1 9 times/s (110 ms) 4.5 times/s (218 ms) 100 ms
SLOW2 4.7 times/s (210 ms) 2.3 times/s (418 ms) 200 ms
Conditions: Auto-range: OFF, Auto-zero: OFF, Calculation: OFF, Display: OFF,
Trigger delay: 0 sec, and GPIB data output
