7351 Series Digital Multimeter Operation Manual
7.1.2 AC Voltage Measurement (ACV, ACV(AC+DC))
7-2
7.1.2 AC Voltage Measurement (ACV, ACV(AC+DC))
Measurement method True RMS measurement, RMS display
Input range 5% or more of a full scale
Crest factor 3:1 at a full scale (This is restricted to the maximum allowable applied
voltage.)
Temperature coefficient (1/10 of measurement accuracy that includes the additional error)/C
in
each range and frequency range
Response time Approx. 1 s (Time until the measurement value reaches within 0.1% of
the final value in the same range)
ACV
Input
terminal
Range
Maximum display Resolution
Input impedance
FAST/MED SLOW1, 2 FAST/MED SLOW1, 2
V-COM 200 mV 199.99 199.999 10 V1 V
2000 mV 1999.9 1999.99 100 V10 V
20 V 19.999 19.9999 1 mV 100 V 1 M2%, 140 pF or less
200 V 199.99 199.999 10 mV 1 mV
700 V 749.9 749.99 100 mV 10 mV
RATE
setting
Range
Measurement accuracy *1 (% of reading + digits)
20 Hz - 45 Hz 45 Hz - 100 Hz 100 Hz - 20 kHz 20 kHz - 50 kHz 50 kHz - 100 kHz
FAST/MED 200 mV 0.38+14 0.11+12 0.1+12 0.25+15 0.7+24
2000 mV 0.38+14 0.11+12 0.1+12 0.2+15 0.6+24
20 V 0.38+14 0.11+12 0.1+12 0.2+15 0.6+24
200 V 0.38+14 0.11+12 0.1+12 0.2+15 0.6+24
700 V 0.38+10 0.11+10 0.1+10 - -
SLOW1, 2 200 mV 0.38+140 0.11+120 0.1+100 0.25+150 0.7+240
2000 mV 0.38+140 0.11+120 0.1+100 0.2+150 0.6+240
20 V 0.38+140 0.11+120 0.1+100 0.2+150 0.6+240
200 V 0.38+140 0.11+120 0.1+100 0.2+150 0.6+240
700 V 0.38+100 0.11+100 0.1+100 - -
*1 For sinusoidal wave input
