7351 Series Digital Multimeter Operation Manual
8.1.2 Replacing a Protection Fuse
8-3
8.1.2.2 How to Replace Protection Fuses
1. Rotate the fuse cap in the counter-clockwise direction by using a flathead screw-
driver and remove the fuse.
2. Replace with a fuse, which is compliant with the standard and listed in Table 3-
1, and secure the fuse cap.
Figure 8-2 Input Terminal Protection Fuse
A protection fuse for the 10 A current input terminal is assembled inside this instrument.
Measure the resistance between the 10 A and COM terminals. If the protection fuse is open, contact ADC
CORPORATION or a sales representative to repair this instrument.
