5.8 Trigger Function
5-13
5.8 Trigger Function
The trigger system of this instrument allows trigger detection and the sampling start to be delayed.
Figure 5-3 shows the trigger model.
In this figure, the external trigger signal and complete signal output are described for illustrative purposes of
the trigger model.
Figure 5-3 Trigger Model
INIT or
INIT:CONT?==ON
:ABORt
*RST
PON
DCL
No
*2
Yes
INIT:CONT?==ON
No
Device action (Measurement/Calculation/Memory store)
Yes
SOURce
TRIGer:SOURce:IMMediate
TRIGer:SOURce:MANual
TRIGer:SOURce:EXTernal
TRIGer:SOURce:BUS
INITiate state
TRIGger waiting state
Waiting for
TRIGger:DELay
Detecting the event start
*2
*1: This action or judgement is disabled when IMMediate is selected for the trigger source.
*2: This judgment is disabled in the LOCAL mode. (Always “Yes”)
*1
COMPLETE output
IDLE state
SAMPle:COUNt
Terminate?
Yes
No
*1
