7351 Series Digital Multimeter Operation Manual
8.1.2 Replacing a Protection Fuse
8-2
8.1.2.1 How to Check Protection Fuses
Measure the resistance of the protection fuse and check that the fuse is not open.
This instrument can measure the resistance of the protection fuse by connecting the terminals as shown in
Figure 8-1.
a. For the mA terminal
Connect the mA and terminals.
Set the resistance measurement function and measure the resistance of the protection fuse.
b. For the 10 A terminal
Connect the 10 A and terminals.
Set the resistance measurement function and measure the resistance of the protection fuse.
Figure 8-1 How to Check Protection Fuses
a. For the mA terminal
b. For the 10 A terminal
