7351 Series Digital Multimeter Operation Manual
7.1.6 Frequency Measurement (FREQ)
7-8
7.1.6 Frequency Measurement (FREQ)
Measurement method
Reciprocal
A frequency over the above range is displayed but not guaranteed.
Input signal voltage range 100 mVrms to 700 Vrms and 10% of each voltage range or more (sinu-
soidal wave)
(However, the input signal is restricted to the maximum allowable
applied voltage.)
Gate time
Maximum allowable applied voltage
Measurement frequency range
Measurement accuracy
(Sinusoidal wave)
10 Hz - 300 kHz 0.02% of reading
Sampling rate Gate time
Measurement
frequency range
Maximum
measurement period
Maximum display
SLOW 1000 ms 1 Hz to 300 kHz 2.2 s 999999
MED 100 ms 10 Hz to 300 kHz 220 ms 99999
FAST 10 ms 100 Hz to 300 kHz 22 ms 9999
Between V and COM terminals
700 Vrms, 1000 Vpeak, 2.2 10
7
V•Hz
Between COM terminal and chassis 500 V
To Next Page
