7351 Series Digital Multimeter Operation Manual
7.1.9 Measurement Time and Display Digits
7-11
For HOLD ON (Trigger source: BUS)
For HOLD ON (Trigger source: BUS) RS-232
RATE setting
Measurement speed (In Auto-range OFF)
Integration
time
DCV
DCI
2W
LP-2W
ACV
ACI
Continuity
Diode
ACV(AC+DC)
ACI(AC+DC)
FAST 74 times/s (13.5 ms) 42 times/s (23.5 ms) 2 ms
MED (50 Hz) 31 times/s (32 ms) 16 times/s (60 ms) 1 PLC
MED (60 Hz) 35 times/s (28 ms) 18 times/s (53 ms) 1 PLC
SLOW1 9 times/s (111 ms) 4.5 times/s (219 ms) 100 ms
SLOW2 4.7 times/s (211 ms) 2.3 times/s (419 ms) 200 ms
Conditions: Auto-range: OFF, Auto-zero: OFF, Calculation: OFF, Display: OFF,
Trigger delay: 0 sec, and GPIB
RATE setting
Measurement speed (In Auto-range OFF)
Integration
time
DCV
DCI
2W
LP-2W
ACV
ACI
Continuity
Diode
ACV(AC+DC)
ACI(AC+DC)
FAST 19 times/s (51 ms) 18 times/s (53 ms) 2 ms
MED (50 Hz) 14 times/s (69 ms) 11 times/s (90 ms) 1 PLC
MED (60 Hz) 15 times/s (65 ms) 11 times/s (85 ms) 1 PLC
SLOW1 6 times/s (150 ms) 3 times/s (251 ms) 100 ms
SLOW2 4 times/s (248 ms) 2 times/s (449 ms) 200 ms
Conditions: Auto-range: OFF, Auto-zero: OFF, Calculation: OFF, Display: OFF,
and Trigger delay: 0 sec
Baud rate: 9600, Number of data bits: 8, Parity: None, and Number
of stop bits: 1
The measurement time is from the *TRG command input the
waiting time of the integration until measured data is output by
using the MD? command.
