7351 Series Digital Multimeter Operation Manual
3.3.1 Input Cable
3-6
2. To reduce the effects of short-term stability in high resistance (in the order of M) or high sensitivity
(in the order of V) measurements, use the optional input cable A01001 in which the HI side is
shielded.
The red wire of A01001 is shielded. Do not cut the joint.
The rating of the probe decreases to 33 VAC and 70 VDC when the alligator clip adapter is attached.
Alligator clip adapter
Barrier
Probe
Protect tip
A01001 (sold separately)
(Internal structure)
Red
Black
Red clip
Black clip
Barrier
Joint
Do not cut here.
To Next Page
