8 I/F
BUS Interface selection (This selection differs depending on the model or option.)
GPIB/RS-232/USB *1
GP.Adr GPIB address (Only when GPIB is selected for the interface)
0 to 30
USBid USB ID (Only when USB is selected for the interface)
1 to 127
HEADR Header
OFF/ON
T.Only Addressable/Talk only (Only when GPIB or RS-232 is selected for the inter-
face)
OFF/ON
LANG Command language selection (This selection differs depending on the inter-
face selection.)
ADC/SCPI/R6451
CONT Initial value selection of the Continue setting
OFF/ON (Only when SCPI is selected as the command language.)
BAUD Baud rate selection (Only when RS-232 is selected for the interface)
9600 - 300 - 600 - 1200 - 2400 - 4800
DATA Data length selection (Only when RS-232 is selected for the interface)
8 bit/7 bit
P-Bit Parity selection (Only when RS-232 is selected for the interface)
NONE/ODD/EVEN
STOP Stop bit selection (Only when RS-232 is selected for the interface)
1 bit/2 bit
ECHO Echo selection (Only when RS-232 is selected for the interface)
OFF/ON
*1: When R6451 is selected as the command language, USB cannot be selected.
When selecting USB, set the command language to ADC in advance.
(b)
