7351 Series Digital Multimeter Operation Manual
5.9.5 Comparator Calculation
5-27
3. Setting the numerical value of the constant
The setting ranges of the High and Low constants are shown below.
1. After the constant setting mode is enabled by pressing , the following items,
which blink, can be selected by pressing and .
• From the most significant digit to the least significant digit in the numeric
value
• Unit prefix
• Decimal point
2. Change the numeric value and unit prefix by using and at the blinking
position.
The unit prefix cycles through the following order.
p n m No unit prefix k M G T
Press the key in this mode if setting the measurement value as the High
or Low constant.
3. Press to apply the setting.
If the constants are set as “High constant < Low constant”, the calculation results may be judged as
“HI and LO”. In this case, HI and LO are displayed at the same time.
4. Buzzer setting
The buzzer output according to the PASS/FAIL judgments can be set.
However, the buzzer output cannot be performed if turns off.
The buzzer setting is performed in BEEP in .
1. Press on the current setting display (BEEP) to enable the buzzer setting mode.
2. Select OFF, FAIL, or PASS by using and .
Constant Setting range Minimum resolution
High
-999999.E +6 to +999999.E + 6 0.000001E - 9
Low
The exponential part is set by using a unit prefix (p, n, , m, k, M, G, T).
MENU
..3.. CALC
BEEP
OFF/PASS/FAIL
