１１６
22.05 Frequency ref 1/ref 2 combination
0: '22.03' ----- Initial value
1: '22.03' + '22.04'
2: '22.03' - '22.04'
3: '22.03' x '22.04'
4: MIN ('22.03', '22.03')
5: MAX ('22.03', '22.03')
Selects a mathematical function between the reference sources selected by parameters
'22.03' (Frequency ref 1 source) and '22.04' (Frequency ref 2 source)
Set 0:
'22.03'
'22.03' (Frequency ref 1 source)
Set 1:
'22.03' + '22.04'
'22.03’ (Frequency ref 1 source) + '22.04' (Frequency ref 2 source)
Set 2:
'22.03' - '22.04'
'22.03' (Frequency ref 1 source) - '22.04' (Frequency ref 2 source)
Set 3:
'22.03' x '22.04'
'22.03' (Frequency ref 1 source) x '22.04' (Frequency ref 2 source)
Set 4:
MIN ('22.03' + '22.04')
MIN '22.03' (Frequency ref 1 source), '22.04' (Frequency ref 2 source)
Set 5:
MAX ('22.03' + '22.04')
MAX '22.03' (Frequency ref 1 source),'22.04' (Frequency ref 2 source)
22.06 Frequency ref 1/ref 2 selection
0: '22.05' setting value ----- Initial value
1: '22.04' setting value
2: DI1
3: DI2
4: DI3
5: DI4
6: DI5
7: DI6
8: DI7
9: DI8
Configures the selection between frequency references 1 and 2
Set 0:
'22.05'
setting value
The frequency is used by
'22.05'(Frequency ref 1 /ref 2 combination)
set value
Set 1:
'22.04'
setting value
The frequency is used by
'22.04' (Frequency ref 2 source)
Set 2~9 : DI1~ DI8
If the digital input which is selected has OFF, it will applied by ref 1
If the digital input which is selected has ON, it will applied by ref 2
