3. General Description
AESFill AF1 is a unique, compact single head liquid filling unit capable of combining with and networking up to 4 heads. Each unit has
a soft touch control screen. As standard, volumes can be entered as low as 1/3 ounces. (10 cc) to volumes greater than 5 Gallons (20
Litres) effortlessly to give repeat fill with an accuracy of up to ±0.5%. Just as easily, the fill speed can be entered to give gentle
foamless filling.
The AESFill AF1 fillers can be networked together to make multi-head liquid filling systems; just plug each unit into power and
connect units to each other with an interface cable, available at time of purchase or through our spare parts department, and they
are networked.
Many units can be networked, but normally up to four units are connected in this manner. Machines with greater than four heads
are usually purchased as AESFill automatic fillers.
If you find that manual filling using the AESFill AF1 fillers is too slow, you can add the automation package and the system can be
automated over any conveyor. There are different options that can be added for different types of products such as neck dive for
cleaner filling or full dive for foamy products. Contact us to learn more about the available options for the AESFill AF1.
The AESPump on the AESFill AF1 can rotate 360 degrees so that you can have your AESPump oriented in any direction. The pump is
fastened onto the machine with sanitary clamp, which makes it very easy to remove while still attached to the nozzle, enabling the
complete liquid contact system to be carried to the clean-up area. With a second pump and nozzle ready to go, changeover to
another product is fast and easy.
Figure 3-1: AF1 Machine
