15. Recommended Spare Parts
Please contact our spare parts department for an exact list of recommended spare parts for your specific machine:
Tel. 514-694-3439
parts@aesus.com.
Table 5: Recommended spare parts
Item #
Qty
Part Description
Electrical
31066
2
10 A Slow Blow Fuse—110 V Machines
44003
2
5 A Slow Blow Fuse—220 V Machines
AESPump
EDT-91003 (Y)
Y = Based on your material selection
3
Polypack Ucup
Select material: Buna-N, Viton, EPDM
EDT-91004 (Y)
Y = Based on your material selection
1
3” Tri-Clover pump end cap seal
Select material: Buna-N, Viton, EPDM
FIL74249
2
12 L Gears Acetron
FIL74755
2
24 L Gears Acetron (Used only if you have a 24L Pump)
EDT-51-25-043A
2
6 L Gears Acetron (Conversion of 12L pumps to 6L pump only. You also need the blank
inserts below).
EDT-51-25-027A
4
6 L Blank Inserts
EDT-51-25-010A
3
Short Bushing
EDT-51-25-010B
1
Long Bushing
EDT-91105 (Y)
Y = Based on your material selection
3
1 ½” Tri-Clover Seal O-Rings
Select material: Buna-N, Viton, EPDM
EDT-91104 (Y)
Y = Based on your material selection
1
¾ “Tri-Clover Seal O-Rings (Depending on your nozzle, you may not need this seal. This
is only if you have a ¾” tri-clover fitting on your nozzle.)
Select material: Buna-N, Viton, EPDM
Nozzle
EDT-91102 (Y)
Y = Based on your material selection
1
O-Ring for Nozzle Spout
Select material:Buna-N, Viton, EPDM
EDT-911ZZ (Y)
Y = Based on your material selection
Z = This number will change based on
the size of your nozzle. Nozzle size is
determined by the outside diameter of
the long portion of the spout and not
the tip.
1
O-Ring for Nozzle Stem Tip
Select material:Buna-N, Viton, EPDM
3/8”
EDT-91110 (B = Buna / V = Viton / E = EPDM)
7/16”
EDT-91111 (B = Buna/ V = Viton / E = EPDM)
1/2”
EDT-91112 (B = Buna/ V = Viton / E = EPDM)
5/8”
EDT-91103 (B = Buna / V = Viton / E = EPDM)
3/4”
EDT-91114 (B = Buna / V = Viton / E = EPDM)
7/8”
EDT-91106 (B = Buna / V = Viton / E = EPDM)
EDT-91101 (Y)
Y = Based on your material selection
1
O-Ring for Nozzle Stem Top
Select material:Buna-N, Viton, EPDM,
EDT-75632
1
Air Coupling Insert 90—1/4”
EDT-75631
1
Air Coupling Insert 1/4”
EDT-75630
2
Panel Mount Bulkhead 1/4” x 1/4”
EDT-77123
1
Nozzle Air Cylinder
Options
ELE106459
1
Backup Sensor Reflects Clear, M12-4P, Keyence
ELE897
2
2 AMP FUSE ATMR
