AESFill AF1C Machine Manual 48/58 Cleaning & Accessories
Exchanging Nozzles & Pumps 10.1
Cleaning a nozzle and pump is not difficult. However, many customers order extra
nozzles and pumps so they can quickly change over to a new product with a fresh
pump and nozzle while the other set is being cleaned.
The pump and nozzle can be removed from the machine all in one piece and taken to
the clean-up areas, then disassembled there.
If the product is very viscous or needs a solvent in order to effect cleaning, the solvent
can be run through the AESFill AF1 in order to begin the cleaning process. (Based on
compatibility with the elastomeric seals.)
Cleaning 10.2
10.2.1 Cleaning the Nozzle
1. Disassemble the nozzle.
2. Remove the O-rings from both the nozzle and valve assembly.
3. Wash components individually with an approved cleaning agent*
4. Thoroughly dry all components before reassembly.
5. Lubricate O-rings with lubricant recommended below.**
10.2.2 Cleaning the Pump
1. Disassemble the pump.
2. Remove the cover seal and shaft seal inside the pump body.
3. Wash components individually with an approved cleaning agent*
4. Thoroughly dry all components before reassembly.
5. Lubricate O-rings with lubricant recommended below.**
*We do not recommend any particular cleaning solutions as product and
local regulations may differ.
**Note: When reassembling the pump and nozzle it is wise to apply a thin
coat of approved lubricant to the pump shaft at the seal and to the nozzle
O-rings, or else the parts may wear rapidly.
** “Superlube grease” by SInco Chemical Corp or other approved lubricant
NOTE: Even though this product is U.S.D.A. approved, please ensure that regulating bodies and
company protocols accept this choice.
Figure 10-3: Dissembling pumps
Careful not to bend the pin
