1260 Infinity Binary Pump User Manual 155
Maintenance
10
Exchanging the Purge Valve Frit or the Purge Valve
1 Using a 1/4 inch wrench disconnect the pump outlet capillary from the
purge valve. Disconnect the waste tube. Beware of leaking solvents due
to hydrostatic pressure.
2 Using the 14 mm wrench, unscrew the purge valve and remove it from
the purge valve holder.
3 Remove the seal cap from the purge valve.
4 Using a pair of tweezers or a toothpick remove the frit.
EjbedjiaZiXVe^aaVgn
Ejg\ZkVakZ
LVhiZijWZ
HZVaXVe
KVakZWdYn
EI;:[g^il^i]\gddkZ
