46 1260 Infinity Binary Pump User Manual
3 Installing the Pump
Installing the Binary Pump
1 Place the module on the bench in a horizontal position.
2 Ensure the power switch on the front of the pump is OFF (switch
stands out).
Figure 14 Front of Binary Pump
3 Connect the power cable to the power connector at the rear of the
module.
HiVijh>cY^XVidg
EdlZghl^iX]
HZg^VacjbWZg
