Agilent Technologies 35670A Quick Start Guide

To select an instrument mode
1
Press [
Inst Mode
].
2 Press [
FFT ANALYSIS
].
or
Press [
OCTAVE ANALYSIS
] to select Realtime Octave Measurements
(Option 1D1 only).
or
Press [
ORDER ANALYSIS
] to select Computed Order Tracking (Option 1D0 only).
or
Press [
SWEPT SINE
] to select Swept Sine Measurements (Option 1D2 only).
or
Press [
CORRELATN ANLYSIS
].
or
Press [
HISTOGRAM/TIME
] to select histograms and time domain.
The analyzer can make measurements that fall into six broad categories, some
available as special options. These categories are called instrument modes.
You should select an instrument mode before specifying other measurement
parameters. Instrument modes are not coupled. Parameters set in one instrument
mode are independent of parameters set in the other modes.
For more information on the six instrument modes, use online help.
The Basics Agilent 35670A Quick Start Guide
8
