To set the analyzer’sGPIBaddress
1
Press [
Local/GPIB
].
2 Verify the analyzer’s GPIB address at the top of the display.
3 To change the address, press [
ANALYZER ADDRESS
]<number>[
ENTER
].
You can create an GPIB system by connecting your analyzer to other devices with
GPIB cables. For example, you create a simple GPIB system when you connect the
analyzer to an GPIB plotter. To make the system function properly, you must assign a
unique address to each attached device—even the analyzer.
The analyzer’s address is set to 11 at the factory. Valid values include all integers
from 0 through 30.
Current GPIB Address
Settings
Setting Up Agilent 35670A Quick Start Guide
14
