Agilent Technologies 35670A Quick Start Guide

To select measurement data
1
Select the active traces. (See “To select the active trace,” the first task in this section.)
2 Press [
Meas Data
].
3 Press [
CHANNEL 1 2
]
or
Press [
CHANNEL 1 2 3 4
] (option AY6). The analyzer steps through the channel
selections as you press [
CHANNEL 1 2 3 4
].
4 Press one of the measurement data softkeys. The [
MORE CHOICES
] softkey displays
another menu of measurement data selections.
If measurement data is not available, its softkey label is ghosted (displayed using
half-bright characters). The availability of trace data is limited by:
• your selection of instrument mode (See “To select an instrument mode” in the first
section.)
• the number of active channels
Working with the Display Agilent 35670A Quick Start Guide
20
