Intermodulation Distortion
Measurement Lower Limit Upper Limit
(dBfs)
Measured Value
(dBfs)
Pass/Fail
Two Ch, F1+F2, 1952 Hz, Ch 1
−80
Two Ch, F1+F2, 1952 Hz, Ch 2
−80
Two Ch, F1−2F2, 1048 Hz, Ch 1 −80
Two Ch, F1−2F2, 1048 Hz, Ch 2 −80
Two Ch, F1+F2, 48.048 kHz, Ch 1
−80
Two Ch, F1+F2, 48.048 kHz, Ch 2
−80
Two Ch, F1+F2, 33.024 kHz, Ch 1
−80
Two Ch, F1+F2, 33.024 kHz, Ch 2
−80
Two Ch, F1−2F2, 49.096 kHz, Ch 1 −80
Two Ch, F1−2F2, 49.096 kHz, Ch 2 −80
Four Ch, F1+F2, 1952 Hz, Ch 1
−80
Four Ch, F1+F2, 1952 Hz, Ch 2
−80
Four Ch, F1+F2, 1952 Hz, Ch 3
−80
Four Ch, F1+F2, 1952 Hz, Ch 4
−80
Four Ch, F1−2F2, 1048 Hz, Ch 1 −80
Four Ch, F1−2F2, 1048 Hz, Ch 2 −80
Four Ch, F1−2F2, 1048 Hz, Ch 3 −80
Four Ch, F1−2F2, 1048 Hz, Ch 4 −80
Four Ch, F1+F2, 24048 Hz, Ch 1
−80
Four Ch, F1+F2, 24048 Hz, Ch 2
−80
Four Ch, F1+F2, 24048 Hz, Ch 3
−80
Four Ch, F1+F2, 24048 Hz, Ch 4
−80
Four Ch, F1+F2, 17488 Hz, Ch 1
−80
Four Ch, F1+F2, 17488 Hz, Ch 2
−80
Four Ch, F1+F2, 17488 Hz, Ch 3
−80
Four Ch, F1+F2, 17488 Hz, Ch 4
−80
Four Ch, F1−2F2, 24096 Hz, Ch 1 −80
Four Ch, F1−2F2, 24096 Hz, Ch 2 −80
Four Ch, F1−2F2, 24096 Hz, Ch 3 −80
Four Ch, F1−2F2, 24096 Hz, Ch 4 −80
Serial Number:_______________________Report Number:____________________
Test Date:___/___/___
Verifying Specifications Agilent 35670A
Performance Test Record - Four Channel
16 of 20
