Agilent Technologies 35670A - To display measurement data-one channel, one trace

Cross Talk
Measurement Lower Limit Upper Limit
(dBVrms)
Measured Value
(dBVrms)
Pass/Fail
Source-to-Ch 1
−126
Source-to-Ch 2
−126
Source-to-Ch 3
−126
Source-to-Ch 4
−126
Receiver Ch 1, Driver Ch 2, 3, 4
−126
Receiver Ch 2, Driver Ch 1, 3, 4
−126
Receiver Ch 3, Driver Ch 1, 2, 4
−126
Receiver Ch 4, Driver Ch 1, 2, 3
−126
Single Ch Phase Accuracy
Measurement Lower Limit
(deg)
Upper Limit
(deg)
Measured Value
(deg)
Pass/Fail
Positive slope, Ch 1
−4
4
Positive slope, Ch 2
−4
4
Positive slope, Ch 3
−4
4
Positive slope, Ch 4
−4
4
Negative slope, Ch 1
−4
4
Negative slope, Ch 2
−4
4
Negative slope, Ch 3
−4
4
Negative slope, Ch 4
−4
4
Serial Number:_______________________Report Number:____________________
Test Date:___/___/___
Agilent 35670A Verifying Specifications
Performance Test Record - Four Channel
