External Trigger
Measurement Lower Limit
(%)
Upper Limit
(%)
Measured Value
(%)
Pass/Fail
8 V Pos
−10
10
8 V Neg
−10
10
−8 V Pos −10
10
−8 V Neg −10
10
Tach Function (option D01 only)
Measurement Lower Limit
(%)
Upper Limit
(%)
Measured Value
(%)
Pass/Fail
Trigger level +8V Pos
−10
10
Trigger level +8V Neg
−10
10
Trigger level −8V Pos −10
10
Trigger level −8V Neg −10
10
Input Resistance
Measurement Lower Limit
(%)
Upper Limit
(%)
Measured Value
(%)
Pass/Fail
27 dBVrms, Ch 1
−10
10
9 dBVrms, Ch 1
−10
10
−11 dBVrms, Ch 1 −10
10
27 dBVrms, Ch 2
−10
10
9 dBVrms, Ch 2
−10
10
−11 dBVrms, Ch 2 −10
10
27 dBVrms, Ch 3
−10
10
9 dBVrms, Ch 3
−10
10
−11 dBVrms, Ch 3 −10
10
27 dBVrms, Ch 4
−10
10
9 dBVrms, Ch 4
−10
10
−11 dBVrms, Ch 4 −10
10
ICP Supply
Measurement Lower Limit Upper Limit Measured Value Pass/Fail
Ch 1 Open Circuit Voltage
26 Vdc 32 Vdc Vdc
Ch 2 Open Circuit Voltage
26 Vdc 32 Vdc Vdc
Ch 31 Open Circuit Voltage
26 Vdc 32 Vdc Vdc
Ch 4 Open Circuit Voltage
26 Vdc 32 Vdc Vdc
Ch 1 Current
2.75 mA 5.75 mA mA
Serial Number:_______________________Report Number:____________________
Test Date:___/___/___
Verifying Specifications Agilent 35670A
Performance Test Record - Four Channel
18 of 20
