Agilent Technologies 35670A Service Guide

Flatness
Measurement Lower Limit
(dB)
Upper Limit
(dB)
Measured Value
(dB)
Pass/Fail
27 dBVrms, 99.84 kHz, One Ch, Ch 1
−0.2
0.2
9 dBVrms, 99.84 kHz, One Ch, Ch 1
−0.2
0.2
−11 dBVrms, 99.84 kHz, One Ch, Ch 1 −0.2
0.2
27 dBVrms, 51.2 kHz, Two Ch, Ch 1
−0.2
0.2
27 dBVrms, 51.2 kHz, Two Ch, Ch 2
−0.2
0.2
9 dBVrms, 51.2 kHz, Two Ch, Ch 1
−0.2
0.2
9 dBVrms, 51.2 kHz, Two Ch, Ch 2
−0.2
0.2
−11 dBVrms, 51.2 kHz, Two Ch, Ch 1 −0.2
0.2
−11 dBVrms, 51.2 kHz, Two Ch, Ch 2 −0.2
0.2
Amplitude Linearity
Measurement Lower Limit
(dB)
Upper Limit
(dB)
Measured Value
(dB)
Pass/Fail
13 dBVrms, Ch 1
−0.0615
0.061
13 dBVrms, Ch 2
−0.0615
0.061
−1 dBVrms, Ch 1 −0.105
0.104
−1 dBVrms, Ch 2 −0.105
0.104
−15 dBVrms, Ch 1 −0.33
0.318
−15 dBVrms, Ch 2 −0.33
0.318
−29 dBVrms, Ch 1 −1.551
1.316
−29 dBVrms, Ch 2 −1.551
1.316
−43 dBVrms, Ch 1 −13.823
5.088
−43 dBVrms, Ch 2 −13.823
5.088
−53 dBVrms, Ch 1 −30.116
10.896
−53 dBVrms, Ch 2 −30.116
10.896
A Weight Filter
Measurement Lower Limit
(dB)
Upper Limit
(dB)
Measured Value
(dB)
Pass/Fail
Ch 1, 10 Hz
−5
2
Ch 2, 10 Hz
−5
2
Ch 1, 31.62 Hz
−1
1
Ch 2, 31.62 Hz
−1
1
Serial Number:_______________________Report Number:____________________
Test Date:___/___/___
Agilent 35670A Verifying Specifications
Operation Verification Test Record - Two Channel
7of10
