Agilent Technologies 35670A Service Guide

Measurement Lower Limit
(dB)
Upper Limit
(dB)
Measured Value
(dB)
Pass/Fail
Ch 1, 100 Hz
−0.7
0.7
Ch 2, 100 Hz
−0.7
0.7
Ch 1, 1000 Hz
−0.7
0.7
Ch 2, 1000 Hz
−0.7
0.7
Ch 1, 10000 Hz
−3
2
Ch 2, 10000 Hz
−3
2
Ch 1, 25120 Hz
−4.5
2.4
Ch 2, 25120 Hz
−4.5
2.4
Channel Match
Measurement Lower Limit Upper Limit Measured Value Pass/Fail
Two Ch, 2/1, 7 dBV FS Mag
−0.04 dB
0.04 dB dB
Two Ch, 2/1, 7 dBV FS Phs
−0.5 deg
0.5 deg deg
Two Ch, 2/1, −13 dBV FS Mag −0.04 dB
0.04 dB dB
Two Ch, 2/1, −13 dBV FS Phs −0.5 deg
0.5 deg deg
Two Ch, 2/1, −33 dBV FS Mag −0.04 dB
0.04 dB dB
Two Ch, 2/1, −33 dBV FS Phs −0.5 deg
0.5 deg deg
Two Ch, 2/1, 7 dBV −20dBfs Mag −0.08 dB
0.08 dB dB
Two Ch, 2/1, 7 dBV −20dBfs Phs −0.5 deg
0.5 deg deg
Serial Number:_______________________Report Number:____________________
Test Date:___/___/___
Verifying Specifications Agilent 35670A
Operation Verification Test Record - Two Channel
8of10
