Agilent Technologies 35670A - To set up a waterfall display

Frequency Accuracy
Measurement Lower Limit
(kHz)
Upper Limit
(kHz)
Measured Value
(kHz)
Pass/Fail
50 kHz
49.9985 50.0015
Single Ch Phase Accuracy
Measurement Lower Limit
(deg)
Upper Limit
(deg)
Measured Value
(deg)
Pass/Fail
Positive slope, Ch 1
−4
4
Positive slope, Ch 2
−4
4
Negative slope, Ch 1
−4
4
Negative slope, Ch 2
−4
4
Tach Function (option D01 only)
Measurement Lower Limit
(%)
Upper Limit
(%)
Measured Value
(%)
Pass/Fail
Trigger level +8V Pos
−10
10
Trigger level +8V Neg
−10
10
Trigger level −8V Pos −10
10
Trigger level −8V Neg −10
10
Serial Number:_______________________Report Number:____________________
Test Date:___/___/___
Agilent 35670A Verifying Specifications
Operation Verification Test Record - Two Channel
9of10
