Agilent Technologies 35670A

ICP Supply
Measurement Lower Limit Upper Limit Measured Value Pass/Fail
Ch 1 Open Circuit Voltage
26 Vdc 32 Vdc Vdc
Ch 2 Open Circuit Voltage
26 Vdc 32 Vdc Vdc
Ch 1 Current
2.75 mA 5.75 mA mA
Ch 2 Current
2.75 mA 5.75 mA mA
Source Amplitude Accuracy
Measurement Lower Limit
(%)
Upper Limit
(%)
Measured Value
(%)
Pass/Fail
1 kHz, 0.1 Vpk
−4
4
1 kHz, 3.0 Vpk
−4
4
1 kHz, 5.0 Vpk
−4
4
Source Flatness
Measurement Lower Limit
(dB)
Upper Limit
(dB)
Measured Value
(dB)
Pass/Fail
12.8 kHz
−1
1
25.6 kHz
−1
1
51.2 kHz
−1
1
102.4 kHz
−1
1
Source Distortion
Measurement Lower Limit Upper Limit
(dBc)
Measured Value
(dBc)
Pass/Fail
12.8 kHz
−60
51.2 kHz
−40
102.4 kHz
−40
Serial Number:_______________________Report Number:____________________
Test Date:___/___/___
Verifying Specifications Agilent 35670A
Operation Verification Test Record - Two Channel
10 of 10
