4Sample Gas Handling
Manual injection kits
Agilent 990 Micro GC User Manual 59
Table 12 G3588-68865 Septum nut injection port shipping kit
#
*
*See Figure 23.
Part Number Description Quantity Unit
1 G3588-60865 Manual injection with Septum 1 EA
2 CP742990 Support ZF2SI 1 EA
3 CP742984 Septum Low bleed 1 EA
4 2815892301 POLYURETHANE,1/16inx1/8inx25ft,CLEARTUB. 1 RL
5 CP86757 SCR-SKT Button-HD T-20 M4X.7 8 SST Zn 2 EA
6 CP742983 Septum injection port Assy 1 EA
7 0100-0053 Stainless Nut 1/16 in 1 EA
8 CP4625 Vesper Ferrule 1/16 x 0.8mm 10pk 2 EA
9 CP179463 GLASSSL.ID 1.0 RED 27 CM
Figure 23. Septum nut injection port (p/n G3588-68865)
