122
Repairing the Autosampler
Metering Seal and Plunger
8 Carefully insert the plunger into the base.
Reassemble the metering head assembly.
9 Press the plunger into the seal.
10 Install the fixing bolts. Tighten the bolts
securely.
11 Install the metering head assembly in the
autosampler. Ensure the large hole in the
metering head is facing downwards.
12 Reinstall the capillaries.
On completion of this procedure:
❏ Install the front cover.
❏ Select “End” in the maintenance function
“Change piston” (see “Change Piston” on
page 83).
