Agilent Technologies Helium Leak Detector
60
DRAFT 12
/11/17
System Pressure Wait Indicates that the system (spectrometer) pressure is too high to light the ion
source filament.
System Ready Indicates that the system is ready for testing. This message appears only during
the initial startup and is cleared after the first test cycle.
Zeroing Indicates that the leak detector is in the process of Zeroing out a background
signal. The Zero routine is initiated automatically during the startup and
calibration routines, or manually when the operator presses the Zero button on
the Home screen.
Zeroing Wait Indicates that the system is setting the initial zero values during the startup
routine.
Table 3-2 Leak Detector Condition States (Continued)
Display Description
