106 Agilent InfiniiVision 3000 X-Series Oscilloscopes User's Guide
6 Digital Channels
6 For high- speed signals, connect a ground lead to the probe lead,
connect a grabber to the ground lead, and attach the grabber to ground
in the device under test.
7 Repeat these steps until you have connected all points of interest.
