98 Agilent InfiniiVision 3000 X-Series Oscilloscopes User's Guide
4 Math Waveforms
Use the Units/Code softkey to specify the analog value equivalent of each
increment in the bus data value.
Use the 0 Offset softkey to specify the analog value equivalent of a bus data
value of zero.
Use the Units softkey to specify the type of values the bus data represents
(volts, amps, etc.).
See Also • "Chart Logic Bus Timing" on page 96
