Installation 3
Agilent SPS 4 Autosampler User’s Guide 33
The unit should be lifted/moved from the positions shown in Figure 4.
One person should be at the front and one person should be at the rear of
the unit. Bend at the knees if lifting from a low position.
Figure 4 Lifting positions for removing the autosampler from shipping carton
Place the unit on a suitable bench and check all of the items you have
received against the packing list. A typical autosampler configuration
could include the following items:
• Spill tray
• Rack location mat
• Sample probe *
• Standards rack *
• Sample racks *
• Wash reservoir kit *
• Communications cable (USB) *
• Power supply cable including an AC adapter (as appropriate for your
location) **
• Tubing (including 3- bridge pump tubing) *
*: These items are packed in an accessory kit box.
**: This item is packed in another box.
At least one
person lifting
from rear.
At least one
person lifting
from front.
Note: Remove
these plastic
inserts before
lifting unit.
