Page 88 VK 7025 Dissolution Apparatus Revision H, 11/10
Operation Operator’s Manual P/N 70-9033
Varian, Inc.
Step 5. Enter a delivery increment time in mm:ss format and press ENTER. The
maximum acceptable value is 59:59.
Step 6. Press ESC to return to the Method Menu 1 screen.
When all the appropriate parameters have been entered on the Method Menu 1 screen,
select MENU 2. The Method Menu 2 screen displays.
Following is a description of the Method Menu 2 screen options:
When all appropriate parameters have been entered on the Method Menu 2 screen,
press ESC twice to return to the Method Menu screen. Select STORE METHOD to save
the previously entered information (see “Storing Methods” on page 90). If you do not
Option Response
Final Spin RPM To program a final spin, select FINAL SPIN RPM. The cursor
flashes. Enter the desired speed in xxx format. The acceptable
range is 10 to 250 RPM. Press ENTER. Press to clear
unwanted or incorrect entries.
Final Spin Time Select FINAL SPIN TIME to set the final spin time. The cursor
flashes. Enter the desired spin time in hhh:mm:ss format and
press ENTER. The maximum allowable time is 999:59:59.
Sample Vessel Temp This option is only available if AutoTemp is enabled.
To read the initial vessel temperature, select INITIAL to toggle
between
ENABLED or DISABLED.
Note: initial vessel temperature is only available if the
apparatus selected is paddles.
To read the final vessel temperature, select FINAL to toggle
between
ENABLED or DISABLED.
Alarm Point Select ALARM POINT to set an alarm to sound during the test.
Enter the desired alarm time in hhh:mm:ss format and press
ENTER.
To Next Page
